Marine Salvage Airbags Explosion-Proof Marine Launching Airbag
Marine Salvage Airbags
1. Marine airbags and salvage airbag are widely used in maritime
salvage AIDS in floating, including the rescue of stranded ships or
AIDS in floating and sinking ships and so on. Due to the unexpected
and time-sensitive nature of maritime salvage projects, if the
salvage company adopts conventional lifting methods, it is often
subject to large lifting equipment or needs to spend high costs. By
adopting the auxiliary technology of salvage airbag, the salvage
company can complete the salvage work quickly and flexibly.
2. The Marine salvage airbags made of flexible materials is
flexible and multi-purpose, which can be folded or rolled into a
cylinder for storage and transportation or diving, greatly
improving the salvage ability of the salvage company. The salvage
airbag can be inserted into the flooded cabin or fixed to the
sunken ship deck, which has little force on the unit area of the
hull and is beneficial to the safety of the hull. The influence of
hydrological condition is relatively small when the salvage airbags
dives, and the underwater operation efficiency is high.
Marine salvage airbag performance and specifications
| Diameter | Layer | Working pressure | Working height | Guaranteed bearing capacity per unit length(T/M) |
| D=1.0m | 6-8 | 0.18MPa-0.22MPa | 0.5m-0.8m | ≥13.7 |
| D=1.2m | 6-8 | 0.17MPa-0.2MPa | 0.6m-1.0m | ≥16.34 |
| D=1.5m | 6-8 | 0.16Mpa-0.18MPa | 0.7m-1.2m | ≥18 |
| D=1.8m | 6-10 | 0.15MPa-0.18MPa | 0.7m-1.5m | ≥20 |
| D=2.0m | 8-12 | 0.17MPa-0.2MPa | 0.9m-1.7m | ≥21.6 |
| D=2.5m | 8-12 | 0.16MPa-0.19MPa | 1.0m-2.0m | ≥23 |
| Size | Diameter | 1.0m,1.2m,1.5m,1.8m,2.0m,2.5m,2.8m,3.0m |
Effective Length | 8m, 10m,12m,15m,16m, 18m,20m,22m,24m,Etc. |
| Layer | 4layer,5layer,6layer,8layer,10layer,12layer |
| Remark: |
According to different launching requirements, different ship types
and different ship weights, the slope ratio of berth is different,
and the size of Marine airbag is different.
If there are special requirements, can be customized.
|
Marine launching Airbag accessories
Marine salvage airbag product display
Service tenet:
Integrity management, quality first; Create a world famous brand,
do a hundred years of enterprise;
Rigorous and pragmatic, considerate; Serve every user attentively.
After-sales service:
1. All products of the company are produced in strict accordance
with ISO17357:2014 standards.
2, the company's products in normal use, the life of 8-10 years.
3, the company will carry out strict inspection on each product
before leaving the factory, to ensure that all products without any
quality problems before leaving the factory, so that every user can
rest assured with.
4, the company's product quality warranty period of 2 years,
quality problems occurred during the warranty period free repair or
replacement.
5. Responsible for guiding repair and maintenance process, and
long-term supply of repair materials and tools.
6. Instruct or participate in the implementation and application of
products to various projects.
7. Provide pre-sale, in-sale and after-sale services
